B5240M

Output Power 输出功率:10-110W

Weight 重量: 200g(Approx.)

Brushless DC Motor-Typical Application（In development）

直流无刷电机-典型应用（研发中）Specialized For Automotive Parts: Water Pump

专用于汽车部件：水泵

Model

型号

Voltage(V) 电压

No Load 空载

Rated Load 额定负载

Stall 堵转

Operating Range

Rated

Speed (rpm)

Current (A)

Torque (mNm)

Speed (rpm)

Current (A)

Output P. (W)

Torque (mNm)

Current (A)

B5240M-S01

8~48

36

8636

0.52

150

6014

3.45

94

494

10.17

Notice: Data in this typical specification sheet are for other certain customer. Voltage, rated torque, speed, current, power and shaft extension feature & dimension can be changed to meet customer specific requirement.

注意：上述规格仅针对特定客户，电压、扭矩、转速、电流、功率、输出轴的特征和尺寸等都可以按照客户的特殊要求进行调整。
